ADL702 2D USB Desktop QR Code scanner

  • QR code scanner able to accurately decode digital barcode (1D&2D)
  • Professional mobile phone barcode reading
  • Ultra-sensitive self-induction
  • Large window ultra-thin design
  • Soft lighting treatment
  • Fast scanning speed, high sensitivity, stable performance, and better recognition capacity
You are here:

Share this product



ADL702 USB Desktop 2D QR code scanner is greatly suitable for wide temperature environments, which kind of desktop scanner decodes electronic barcodes (1D&2D) on mobile screens rapidly and accurately to avoid irritating the eyes and unpleasantness to users.

Fast scanning speed, high sensitivity, durability, and better recognition capacity for the QR code scanner make it popular in supermarkets, grocery stores, libraries, drugstores, retail shops, food services, and other businesses that necessitate scanning payment.

Handsfree 1D 2D QRcode Scanner desktop will be activated automatically once an item keeps moving, and it will read the barcode under the window to transfer to your pos machine.

Other types of barcode scanners can be supported for you, and you could download the vmax product catalog 2023 for a browse.

Physical parameter
Net weight145.5g
Size92mm L *74mm W * 54mm H
Interfaces SupportedUSB、RS232
Performance parameter
Light source5600K LEDs(illumination)
Image Sensor752pixels(H)*480 pixels(V)
Print contrast20%PCS
Field of view115°(H) * 90°(V)
Roll:0-360°、Pitch:±65°or greater、Yaw:±60°or greater
Power supplyDC 5V±10%@220mA

Symbology Decode Capability

1D: UPC, EAN, CODE 128, CODE 39, CODE 93, CODE 11, Matrix 2 of 5,

Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.

2D: QR Code, Micro QR, PDF 417, Micro PDF 417, Data Matrix, Maxicode, Aztec, Hanxin, etc.

Environmental Parameters
Operation temperature-20℃ to 50℃
Storage temperature-40℃ to 70℃
Relative humidity5% to 95%(Non condensing)
Ambient light100,000Lux
Drop height1.5m
