GS-2406T 4 Inch Desktop Barcode Printer in transfer thermal or direct thermal printing method optional, provides Windows printer utility, Windows SDK, and Android SDK optional, and supports 1d 2d bar code printing due to business demands. The GS-2406T thermal printer belongs to one kind of Economic Barcode Printer in 203 DPI, ( or other 300 DPI Thermal Printer Optional ) suitable for Shipping Labels, Barcodes, and Receipts with our extensive selection of printers and accessories.
For more assistance, speak with our printer expert to ask about your needs.
PRINTER MODEL | GS-2406T | |
Level | Economic Barcode Printer | |
Resolution | 8dots/mm (203DPI) | |
Printing Method | Thermal Transfer & Direct Thermal | |
Max. print speed | 152.4mm (6″)/second | |
Max. print width | 108mm (4.25″) | |
Max. print length | 2,794mm (110″) | |
CPU | 400MHZ, 32-bits, ARM9 | |
Memory RAM | 64MB SDRAM | |
Memory ROM | 32MB Flash Memory | |
Interface | USB 2.0 High-Speed 480Mbps USB Host 2.Q, for scanner or PC keyboard | |
Real Time Clock | N/A | |
Buzzer | NZA | |
Dealer options | NZA | |
Sensors | Head open sensor; Ribbon end sensor; Reflective sensor (moveable), Transmissive sensor (moveable) | |
Power | External universal switching power supply Input: AC 100-240X 2.5A, 50-60Hzz Output: DC24V 2.5A, 60W | |
User Interface | 1 power switch, 2 buttons (Feed & Pause), 3 LEDs (Online, Error; Ribbon status) | |
Internal fonts | 8 alpha-numeric bitmap fonts True type font engine (need download scalable font file) | |
1D Barcode | Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-Af UPC-E, UCC-128, CodabacEAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy- PostCode, Telepen | |
2D Barcode | QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCode, Aztec Code, Data Matrix | |
Rotation | Font and barcode support 0,90,180, 270 degree | |
Printer language | Compatible to EPL, ZPL, ZPL II, DPL, TSPL | |
Ribbon | 300 M long, max. OD 67mm, 1 “core (ink coated outside) | |
Ribbon width | 30mm~110mm (1.18,,~4.3H) | |
Media type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) | |
Media width | 15~112mm(0.6″~4.4″) | |
Media thickness | 0.055~0.254mm (2.17~10mil) | |
Media core diameter | 25.4mm (1″) | |
Label roll capacity | 127mm (5″)OD | |
Label length | 5~2,794mm (0.2,,~110H) | |
Physical dimension | 210mmx180mmx278mm (WHD) | |
Weight | 2.09kg |
