BT40D 2D Wireless HandHeld Barcode Scanner
- Handheld wireless barcode scanners use long-distance wireless communication technology to achieve mobile scanning within 100m (vacant)
- Adopt a high-density 2500mAh lithium-ion battery, fully charged to support continuous work for 5 hours
- Support a variety of high-density, damaged, and deformed barcode scanning
Share this product
Description
BT40D 2D Wireless Handheld Barcode Scanner has adopted a high-density 2500mAh lithium-ion battery, which can operate for 5 hours all the time with being fully charged and is able to support the long working of warehouse goods inventory scanning, and portable handheld barcode scanner can be applied with Bluetooth for convenient and fast businesses needs.
With a radio frequency of 2.4G or Bluetooth connection, the wireless handheld barcode scanner guarantees mobility and productivity. Wireless scanners are available at low prices with your desired.
| Physical Characteristics | |
| Dimensions | 201.10mm x 94.20mmx 101.80mm |
| Voltage | +4.2V±10% VDC |
| Stand-by Current | 165mA |
| Weight | 360g |
| Starting Current | 220mA |
| Work Current | 260mA |
| Performance Characteristics | |
| Image (Pixels) | 640 pixels (H) x 480 pixels (V) |
| Light Source | (Aimer) Red color LED; (Illumination) White color LED |
| Wireless signal | 2.4 -2.5 GHz bandwidth range, Bluetooth V2.0/V3.0/V4.0 |
| Roll / Pitch / Yaw | 65°(Yaw), 65°(Pitch), 360°(Roll) |
| Print Contrast | 20% minimum reflective difference |
| Interfaces Supported | 2.4G, Bluetooth |
| Battery Specification | 3.7/2500mAh Endurance：5 hours |
| Charging Time | 3.5 hours |
| Communication Distance | 100m (open), support storage |
| 100m (open), support storage | 100,000 items (13 characters/item) |
| Symbology Decode Capability | |
| 1D: Codabar,Code 11, Code 39, Code 93, Code 128/EAN128, EAN.UCC Composite, Interleaved 2 of 5, MSI Code,Planet, Standard 2 of 5, Telepen, Matrix 2 of 5,UPC/EAN, etc | |
| 2D: PDF417, QR code, MicroPDF417, MaxiCode, Codablock, Aztec, Dutch Post, DataMatrix, etc. Symbology is turned on by default:Codabar;Code39;Interleaved2of5;NEC2of5，Code93;Code128;GS1-128， | |
| User Environment | |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -30°C to 70°C |
| Humidity | 5% to 95% relative hum idity,non-condensing |
| Shock Specifications | Designed to withstand 1.5m(5’) drops |
| Decode Ranges | |
| Code39(5mil) | 40mm-190mm |
| Code39(13mil) | 60mm-380mm |
