GS-2406T PLUS 4 Inch TT Desktop Barcode Printer
- 300 meter (984′) ribbon supply on a 25.4 mm (1″) core (coated outside)
- TT Barcode Printer with clamshell double-walled strong structure and cover closing buffer design
- Cover closing buffer design and opening lock design.
- Barcode printer with screwdriver-free easy assembling cutter and peeler
- 400 MHz 32-bit ARM9 processor with 64 MB SDRAM, 32 MB Flash memory or 128 MB SDRAM, 128 MB Flash memory.
- Firmware emulates TSPL, EPL, ZPL, ZPL II, DPL
Share this product
Description
GS-2406T PLUS 4-inch Desktop Barcode Printer of Thermal Transfer, clamshell structure with double-walled strength and a cover-closing buffer design. With easy-to-replace auto-cutter, print head, and platen roller, there is less maintenance required for different businesses.
Our cutting-edge 4-inch TT desktop barcode printer delivers smooth efficiency and precision. This modern barcode printer has been created to transform your business’s operations by combining elegant looks with innovative technology to provide unsurpassed performance.
Utilize high-resolution printing to bring your barcodes alive with razor-sharp clarity on every label. The intelligent thermal transfer (TT) mechanism that comes with our printer ensures flawless barcode quality, ensuring precise scans and easy inventory management.
The 4-inch desktop barcode printer, featuring its user-friendly interface and straightforward settings, enables even the most inexperienced user to become a barcode printing master. Wave goodbye to time-consuming installations and welcome increased productivity.
With the 4-inch TT desktop barcode printer, you can propel your business to new heights. This versatile device is the ideal response for effective barcode printing, from retail to logistics, healthcare to production.
Embrace business success, and appreciate technology innovation.
| Level | Standard 4 inch barcode printer |
| Resolution | GS-2406T PLUS: 8dots/mm(203DPI) |
| Printing Method | Thermal Transfer & Direct Thermal Barcode Printer |
| Max. print speed | GS-2406T PLUS: 152mm(6″)/second |
| Max. print width | GS-2406T PLUS: 104 mm (4.1″) |
| Max. print length | GS-2406T PLUS: 2，794 mm (110″) |
| CPU | 400 MHZ, 32 bits, ARM9 |
| Memory RAM | 64 MB SDRAM / 128 MB SDRAM(factory option) |
| Memory ROM | 32 MB Flash Memory / 128 MB Flash Memory(factory option) |
| Interface | • USB 2.0 High Speed 480Mbps • USB Host 2.0, for scanner or PC keyboard • RS-232 (factory option) • Internal Ethernet 10/100Mbps (factory option) • Internal Bluetooth 4.0 (factory option) • Internal WiFi (factory option) |
| Real Time Clock | Optional |
| Buzzer | Optional |
| Dealer options | • Guillotine cutter • Peeler |
| Sensors | • Head open sensor • Ribbon end sensor • Reflective sensor (moveable) • Transmissive sensor (moveable) |
| Power | External universal switching power supply Input: AC 100-240V, 2.5A, 50-60Hz, Output: DC 24V, 2.5A, 60W |
| User Interface | • 1 power switch • 2 buttons (Feed & Pause) • 4 LEDs (Online, Error, Ribbon status, Communication) |
| Internal fonts | • 8 alpha-numeric bitmap fonts • True type font engine (need download scalable font file) |
| 1D Barcode | Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI Pleassy, PostCode, Telepen |
| 2D Barcode | QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix |
| Rotation | Font and barcode support 0, 90, 180, 270 degree |
| Printer language | Compatible to TSPL, EPL, ZPL, ZPL II,DPL |
| Ribbon | 300 M long, max. OD 67 mm, 1″ core (ink coated outside) |
| Ribbon width | 30 mm~110 mm (1.18″~4.3″) |
| Media type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media width | 20~117 mm (0.7″~4.6″) |
| Media thickness | 0.055~0.19 mm (2.16~7.4 mil) |
| Media core diameter | 25.4 mm (1″) |
| Label roll capacity | 127 mm (5″) OD |
| Label length | GS-2406T PLUS: 5~2,794mm(0.2″~110″) GS-3405T PIUS:5~1‚016mm |
| Physical dimension | 280mm(D) x 200mm(W) x 182mm(H) |
| Net Weight | 2.5kg |
| Enclosure | ABS plastic |
| Safety regulation | FCC Class A, CE Class A, CCC, BIS, CB |
| Environment condition | Comply with RoHS, REACH, WEEE |
| Environmental concern | Operation: 5 ~ 40°C, 25 ~ 85% non-condensing Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
| Accessories | • Windows labeling software CD disk • Quick start guide • USB cable • Power cord • External universal switching power supply • 1″ ribbon spindle x 2 for 300M ribbon |
