R210 Bluetooth Wearable Ring Barcode Scanner

  • High-performance MCU, easily identify mainstream 1D and 2D bar codes
  • Bluetooth 4.2 wireless technology, the outdoor transmission distance can reach 30 meters
  • Multiple working modes (storage mode + scan and transfer synchronization mode)
  • Ring barcode scanner support online upgrade, custom development and secondary development
You are here:

Share this product

Description

The R210 wearable ring barcode scanner is tiny enough to be worn on a single finger without fatiguing the user. It’s a wireless barcode scanner that may be carried about with you wherever you go.

Ring barcode scanner has excellent ergonomics and Bluetooth functionality and the ring scanner enables unsurpassed comfort and flexibility of movement.

The R210 wireless ring scanner is excellent for mobile employees in retail, field service, warehouses, logistics, and more who need to swiftly and safely scan barcodes while having both hands free to do operations like selecting, sorting, putting away, and packaging. These time-saving devices make scanning barcodes, handling merchandise, and carrying boxes more efficient.

Performance
Dimension
L51.5mm * W35mm * H45mm
Weight
35g
Voltage
5V
Working current
120mA
Sensor pixel
light source
640 pixels (H)x480 pixels (V)
(Aimer) Red color LED; (Illumination) White color LED
Physical characteristics
Field of view
28°(Horizontal),20°(Vertical)
Rotate tilt deflection
360°(Roll), ±65°(Skew) , ±65°(Pitch)
Print contrast
20% minimum reflective difference
Interfaces
Bluetooth,USB
Motion tolerance
>0.4m/s
Decoding ability
1D bar codes
Codabar、Code39、Interleaved2of5、NEC2of5、Code93、Code128、 Codabar、Code 39、Code 32 Pharmaceutical (PARAF)、Interleaved 2 of 5
NEC 2 of 5、Code 93、Straight 2 of 5 Industial、Straight 2 of 5 IATA
2D bar codes
PDF417、Micro PDF417、GS1 Composite
QR Code、Data Matrix、MaxiCode、Aztec、HANXIN.
Symbology is turned on by default
GS1-128、UPC-A、UPC-E0、EAN/JAN-13、EAN/JAN-8、GS1-DataBar、
PDF417、QR、DM、Aztec
Decoding range
Operating temperature
storage temperature
-20°C to 60°C
-30°C to 70°C
Humidity shock resistance
Ambient light immunity 5 mil (code39)
5% to 95 relative hum idity,non-condensing
Designed to withstand 1.2m(5’) drops
0-100,000 Lux.
40mm-120mm
13 mil (code39)
50mm-400mm
QR(20mil)
30mm-370mm
Wireless parameters
Bluetooth mode
HID,SPP,BLE,virtual Bluetooth
battery capacity
Charging time
380Ma
1.5H
usage time
Greater than 6H (synchronous mode, scan once every second)
Standby time
4 weeks
